            HEC-A8 Series





                Publish Time：2012/7/25   |    Click：1196













    Electrical characteristics ：
    Type
    HEC100-A8
    HEC200-A8
    HEC300-A8
    HEC400-A8
    Rated Current
    100A
    200A
    300A
    400A
    Linear Range
    300A
    400A
    500A
    600A
    Output Voltage
    4V 、 5V
    Accuracy
    ±1%
    Offset Voltage
    ± 20mV
    Hysteresis Error
    ± 15mV
    Temperature Drift
    0.03%/ ℃
    0.025%/ ℃
    Response Time
    ＜ 7μS di/dt=50A/μS
    Power Supply
    ± 12V 、± 15V （± 5% ）
    Current Consumption 18mA
    Isolation 3KV AC 50Hz/min
    Operating Temperature Range -10 ℃ ～ +80 ℃
    Storage Temperature Range -25 ℃ ～ +85 ℃
